Non - Grain Oriented Electrical Steel
Hits:
【Print】
- Open Hours: 24 X 7 online support
- +1 (825) 935-9188 / +86 17717957128
Silicon steel, also known as silicon steel Sheet or Electrical Steel, it is a ferro-silicon soft magnetic alloy steel with very low carbon content, usually containing 0.5% to 4.5% silicon. The addition of silicon can increase the resistivity and maximum permeability of iron to reduce the coercivity, iron loss and magnetic aging.
The difference between oriented silicon steel and non-oriented silicon steel
Non-oriented silicon steel: ferro-silicon alloy with very low carbon content. In the deformed and annealed steel sheet, its grains are distributed randomly. The silicon content of the alloy is 1.5% to 3.0%, or the sum of the silicon and aluminum content is 1.8% to 4.0%. The products are usually cold-rolled plates or strips, which are mainly used to manufacture motors and generators.
Pre:Oriented Electrical Steel Next:None
| ID | 508mm |
| Nominal Thickness | 0.15mm,0.20mm,0.23mm,0.25mm,0.27mm,0.30mm,0.35mm,0.50mm,0.65mm |
| Annealing Temperature | 820±20ºC |
| Annealing Time | 1.5 to 2.5 Hours |
| The Rate of Heating and Cooling | Rapid Heating or Cooling Should Be Forbidden |
| Annealing Atmosphere | Nitriding and Oxidation Atmosphere Must Be Avoided |
| Nominal Width | 20~1500mm |
| Weight | 3~8t |
